LSLB | Stats | Graphs

POSTED ON 8 November, 2023

Farms Graph Stats

This section shows graphs of the Established and Pending connections for current the farms over four time periods: The Daily, Weekly, Monthly, and Yearly.

The types of connections that are counted are:

  • Established: These connections have been confirmed and are marked as ESTABLISHED. For L4xNAT profile farms, this means that there is a connection to the backend server. For HTTP profile farms, this means that there is a connection to the virtual server.
  • Pending: These connections are marked as SYN and have not been confirmed yet. An increase in the number of pending connections means that a higher rate of requests is being received and is not being served.

Each graph also shows the following information:

  • The last value that was gathered.
  • The minimum, maximum, and average values.
  • The Enable data range selector toggle button that selects a range of dates from which the data is to be analyzed.
